Equipment at FabLab Nordvest

Here, you find an overview of current machines at the Lab. The list is not exhaustive but show some of our biggest machines.

Blue Laser

  • Brand: Universal
  • Power: 60 W
  • Work area:  600 mm x 300mm
  • Materials: WOOD/MDF/HDF (3-5mm), Acrylic (6mm), cardboard, paper, fabrics, non-PVC acrylics and other organic materials.
  • File type: Illustrator (AI), Autocad (DXF), JPG & BMP for rastering

Big Laser

  • Brand: Maskinfabrikanten. UNIVERSAL LASER SYSTEMS.
  • Model: AD1000 IQ (sælges ikke længere)
  • Power: 230V50Hz12.8A
  • Work area:  1200 mm x 900 mm
  • Materials: WOOD/MDF/HDF (3-5mm), Acrylic (6mm), cardboard, paper, fabrics, non-PVC acrylics and other organic materials.
  • File type: Illustrator (AI), Autocad (DXF), JPG & BMP for rastering

Quick start guide here.

3D Printers filament

We have two Prusa I3 MK3-type printers. Their build volume is 250 x 210 x 210 mm. We also have two Prusa Minis with a build volume of 180 x 180 x 180 mm.

3D Printers Resin

We have two Anycubic Phonton Mono X printers.

Vinyl Cutter

We have a Graphtech CE6000 (600mm width) vinyl cutter. We also have a heat press to apply your designs to fabrics.

Tufting

We have 5 tufting guns, four 1×1 frames, one bigger frame and all the equipment you need to make your own Rug. Bring your own yarn and remember to clean the guns after use.

Robot arm

We have a Universal Robot UR5.

Maximum lifting capacity: 5 kg

Movement radius: 850 mm

Electronics

We have an electronics area, with power supply, oscilloscope, soldering stations and a small assortment of components.

Woodworkshop

We have a dedicated woodworking area, with assorted hand and power tools (circular saw, router, router table, belt sander, etc).

CNC machines

X-CONTROLLER by Inventables. X-CARVE.
DeWALT 993770. 2018 17-49. D26200-GB.
Type 1. 230V. ~50Hz.  900W. No 16000-27000/min (RPM). A29351.

Our CNC machines can cut wood, plastics, foam, or pretty much anything that is not metal. You will have to bring you own cutting tools (end mills).

Milling Cutter – Makita Ø260mmMLT100N

220-240V~. 6.4A. 50-60HZ. 1500W.
No4300min-1 2019. 8255 >25kg

Milling Cutter – Ujk technology

AXMINSTER. NVRS/2/240V. CE60745. 16(12)A 250VAC 5E4. T85/55. E195428.

1.5HP 220-240VAC. 16A 220-240VAC. 1119W240V ~.

Jointer and Thickness Planer

Güde. GADH 254. 230V/~50Hz. 8500min-1. 1500W. 34kg.

Serienr.82947-2401. GTIN: 4015671851727. Baujahr: 2024. Art.Nr.: 55441

Circular Saw. DeWalt DW701, type 2.

230V~         50Hz 7.5A
No2500-5000/min 1600W
Cut Depth 60mm d1=30mm D=216mm
888751-09 07833
www.2helpU.com

Jigsaw. HEGNER MULTICUT-2

Universal-Feinschnittsäge

Jigsaw. BOSCH

PBD 40 3603 M07 002
220-240V~ 50-60Hz 710W
Ø 13mm no=200-2500/min
122004442 02/2021
